Fully Automatic Bottle Filling Machine

<<Previous

Send Inquiry

Product Code : 11

Product Description

Established in the year 2011, we are leading manufacturer, exporter and supplier of best quality Fully Automatic Bottle Filling Machine. Our experts keep a vigilant eye on the production process of this machine to make sure that the industrial norms and standards are strictly followed. The offered machine is used in diverse industries for filling of bottles automatically in accurate quantity. Moreover, offered Fully Automatic Bottle Filling Machine is inspected by our quality analysts on various parameters to dispatch a hassle free range at prestigious patron's end.

Features:

Robust construction
Long service life
Precisely designed
Hassle-free functionality

Further Details:

With our technical expertise, we are making available to you advanced Automatic RFC Machine Rinser, top plate of which is produced from SS 304. Mounted with UHMWPE bracket, the Bottle Grippers of the machines are made of SS 304 with machining for CNC machine. The offered machines has SS 304 made Rinser jet valve body. Opening of the rinsing nozzle comes with the bottle place over the rinsing jet, which by a mechanical cam can also turns at 180 degree. Our machines get high appreciation in the market for no Bottle no Rinsing arrangement, bottle rinsing with liquid recovery for Re-Use and durable gravity filling mechanism which is made to make it suitable to be used under normal room temperature. The Filling nozzle of SS 316 & SS 304 grade, SS 316 made tank with internal mirror finished polish and no bottle no fill arrangements of our machines also enhance their demand in the market.

Rinser Section:

Rinser top plate is developed of SS 304.
UHMWPE bracket mounted Bottle Gripper
Bottle grippers are made of SS 304 with machining for CNC machine.
SS 304 made rinser jet valve body
Have durable opening of the rinsing nozzle, from where the bottle is turned at 180 degree by a mechanical cam and placed over the rinsing jet.
Reusable liquid recovery bottle rinsing function
No bottle, no rinsing arrangement

Capping Section:

Accurate torque setting for capping head
Comes with fitted individual cap washing arrangement on chute
Detachable control panel
Have advanced sensors that detect the caps in the chute
Hopper for mechanical cap feeder passes the caps into distributors chute
Ideal for application of screw on caps
Imported Gear Box (Italy) Bonfiglioli
Machine is low on maintenance and servicing
No bottle, no cap system is provided
To prevent damages to the machine, it has durable clutch & break system
Variable Speed Through Frequency Drive (VFD)

Specification :

Category	Model RFC(Nos.)	Machine Dimension (mm)	Output (BPM)	Electric Load (HP)
Semi Automatic	2 x 4 x 1		20	22
Automatic	2 x 4 x 2		24	12
Automatic	6 x 8 x 3	1700 x 1300 x 2135	30	6
Automatic	8 x 8 x 4	1740 x 1740 x 2135	40	6
Automatic	12 x 12 x 6	1920 x 1760 x 2135	60	8
Automatic	18 x 18 x 8	2600 x 2020 x 2440	90	8
Automatic	24 x 24 x 10	3000 x 2100 x 2440	120	10

GLOBAL ION EXCHANGE

Contact Us

( *represents compulsory fields )

Describe Your Requirements In Detail*

Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.

Select a file to upload

Other Products in 'Bottle Filling Machines' category

Semi Automatic Bottle Rinsing Machine
